| Features | |||
| ◆ Wide range of AC input voltage90-305VAC; | |||
| ◆ Protections against: short circuit/over load | |||
| ◆ C.C.Output | |||
| ◆ LED load less than 100% | |||
| Input Voltage Range | 90-305VAC | Power Factor | ＞0.9 | ||||||||
| Efficiency | 87% | Humidity | 10~90% RH | ||||||||
| THD | ＜15% | MTBF | ≥150,000 hours, MIL-HDBK-217F(25℃) | ||||||||
| Operation Temperature | -10~60℃ | Safety Standard | CCC(GB19510)、Meet CE(EN61347) | ||||||||
| Storage Temperature | -40~85℃ | EMC Standard | Meet EN55015、EN61347、EN61000、GB17743、GB17625 | ||||||||
| Weight | 90g | Dimensions | 85mm (L) ;74mm (W) ; 28mm (H) | ||||||||
| Applications | Down Light(indoor)，T8 LED tube(external),LED driver(indoor) | ||||||||||
Series
Model
Output
Current Range
Eff.
Ripple
C.C. Mode
*UEL024A-S048048-OP
34-48V，0.48A
±5%
87%
10%Vo
